Dimensions 5.14 in. H x 0.98 in. D x 8.82 in. W
130.5 mm H x 25.0 mm D x 224.0 mm W
Weight 1.4 lbs./.63 kg
Display 7 in. capacitive; 1024 x 600; 350 NIT; Corning
®
Gorilla
®
Glass
Touchpanel Capacitive multi-touch
Backlight Ambient light sensor
Keypad Options Virtual; Bluetooth
®
Expansion Capabilities User accessible Micro SDHC card slot (up to
32GB); expansion module port
Expansion Modules Integrated expansion port for ‘snap-in’
peripherals for Motorola and third party
peripherals
Connectivity Two USB interfaces: 1 USB 2.0 OTG connector
(docking connector) and 1 USB 2.0 Host
connector (expansion module port); HDMI out;
communication via cradle and expansion ports;
USB 2.0 host via expansion module
Notification LED flash; bar code decode
Audio Stereo speakers and dual microphones (one
front and one rear-facing)
CPU Dual core 1GHz each plus graphics accelerator
Operating System Android 2.3.4
Memory 1GB RAM,4GB Flash plus 4GB microSD
(total of 8GB flash memory); user accessible
microSD card slot (supports up to 32GB)
Operating Temp. 32° to 122° F /0° to 50° C
Storage Temp. -4° to 158° F /-20° to 70° C
Drop Specification Multiple 4 ft./1.2 m drop per MIL STD 810G
Sealing IP54
Vibration 4Gs peak, 5hz to 2khz, 1 hour duration per axis
Thermal Shock -4° F to 158° F/-20° C to 70° C rapid transition
ESD 15kv Air, 8kv contact, 2kv charge body
Humidity 10% to 95% RH (Non-condensing)
Development Tools Motorola RhoElements for cross platform
applications
Management Tools Motorola Mobility Services Platform (MSP)
Battery 4620 mA rechargeable Smart Li-Ion; user
replaceable; rapid resume
Battery User Profile Ample power for a full shift
Rear Camera For barcode scanning and image capture:
8MP auto-focus camera with user controllable
LED flash, illumination and aiming; captures
1D and 2D bar codes, photographs, video,
signatures and documents
Front Camera Optimized for video collaboration and low
lighting conditions
Video 720p video
Readability 9,000 ft. candles
WLAN 802.11a/b/g/n
WPAN Bluetooth 2.1 + EDR; integrated antenna
GPS Autonomous GPS
Gyroscope Maintains orientation based on principles of
conservation of angular momentum
Motion Sensor 3-axis accelerometer that enables motionsensing applications for dynamic screen
orientation and power management
Ambient Light Sensor Automatically adjusts display brightness,
keypad and display backlight
Electronic Compass Independent — does not depend on GPS
Accessories include: 1-slot docking USB Charge Cradle; 4-slot docking
cradle charge only; 4-slot battery charger; power supply; USB/charge
cable; 2-way DC cable; hand strap; headset; AC line cord; DC cable;
battery; customizable bezel
For Regulatory information, please visit:
www.motorolasolutions.com/et1
Subject to the terms of Motorola’s hardware warranty statement,
the ET1 is warranted against defects in workmanship and materials
for a period of 1 (one) year from the date of shipment. For complete
warranty statement, go to: http://www.motorola.com/warranty
